·Screen Sizes: 32"
·HD Screen Display
·Built-In Speakers
·WIFI & Bluetooth Enabled
·SuperSign Content Management Software
·Adaptable with AV Control Systems
·Placement Style: Wall Mount
·Screen Sizes: 32"
·HD Screen Display
·Built-In Speakers
·WIFI & Bluetooth Enabled
·SuperSign Content Management Software
·Adaptable with AV Control Systems
·Placement Style: Wall Mount
Mode Name | MS-3201AD |
Screen Size | 32″ |
Active Display Area (mm) | 697.6845mm(W)×392.256mm(H) |
Display Mode | 16:9 |
LCD Type | TFT-LCD |
Resolution | 1920×1080 |
Display Color | 16.7M |
Pixel Pitch(mm) | 0.51075(H)×0.51075(V) |
Brightness(nits) | 300cd/㎡ |
Contrast Ratio | 3000:1 |
Viewing Angle | 178(H) /178(V) |
Response Time | 20ms |
Backlight | LED |
Color system | PAL/NTSC/SECAM |
Remote controller | IR Remote Controller |
Basic Interface | |
USB | x2 |
SD | x1 |
HDMI | x1 |
RJ45 (Internet Access) | x1 |
VGA | x1 |
Speacker | Optional ( 2×5W(9Ω) |
Sopport display format | |
Video format | MPEG1, MPEG2, MPEG4, H.264, WMV, AVI, MOV, JPEG, BMP,PNG |
Image Format | JPEG, BMP,PNG |
Main function | |
O/S system | uCOS |
display Model | loop playback, set time, inter-cut display etc |
location Orientation accuracy | <2mm |
network support | Ethermnet. WIFI, WCDMA wireless peripheral extended |
support image division | 1*video, 4*images. 1*roll titles. 1*weather forcasr area. support free screecn division |
Main hardware | |
CPU | A20 , main frequence 1.0~1,5HZ |
RAM | 1G |
built in stotage | NAND FLASH 4G |
decode resolution | max support 1080 P |
OS | Android 7 |
Menu language | Chinese/English/other language |
Power | |
Power supply | AC100~240V 50 /60 HZ |
Maximum power consumption | ≦115W |
Standby power consumption | <1W |
Working environment | |
working temperature | 0℃~60℃ |
Storage temperature | -40℃~60℃ |
humidity | 10%~90%,no condensation |
Appearance | |
Color/appearance | black,customized metal case |
Installation | wall mount |
Anrecson is a leading manufacturer, specializing in designing&producing LCD products, including touchscreen monitor, open frame monitor, industrial monitor, panel pc, digital signage, CCTV monitor and video wall, 4K Monitor, AHD/CVI/TVI/CVBS 4 in 1 monitor etc. The size ranges from 5 inch to 128 inch.
We own 15 engineers’ R&D department, which can meet your all kinds of customization requirement. We provide fast response and best solution according to each project. And professional equipment includes Pulse wave, shaking, static electricity, and temperature and humidity testing....
Anrecson Brand Monitors are widely used in traffic control center, broadcasting system, military, city square, shopping mall, bank,school and hospital,etc. Devices like ATM, Self-service kiosk, Transportation, Automatic Vending Machine, Gaming Machine, Pos, Medical Treatment, CNC Machine also use our Anrecson monitor.
Our products have got CE, RoHS, FCC, CCC certificates. We also carry out a strict quality management system in accordance with ISO9001 requirements.
